The BMD-341 from u-blox is an advanced, highly flexible, ultra-low power multiprotocol SoM that enables Bluetooth 5 (BLE) and IEEE 802.15.4 (Thread and Zigbee) connectivity for portable, extremely low-power embedded systems. With an Arm® Cortex®-M4F CPU, integrated 2.4 GHz transceiver, and a U.FL connector for an external antenna, the BMD-341 provides a complete RF solution allowing faster time to market with reduced development costs. Providing full use of the Nordic nRF52840's capabilities and peripherals, the BMD-341 can power the most demanding applications, all while simplifying designs and reducing BOM costs. The BMD-341 is an ideal solution for designs that require the latest Bluetooth 5 features or 802.15.4 based networking for Thread. Increased integration with built-in USB and 5.5 V compatible DC/DC supply reduces design complexity and BOM cost while expanding possible applications. BMD-341 designs are footprint compatible with the BMD-300/301/330/360, providing low-cost flexibility for tiered product lineups.
Features
- Based on the Nordic nRF52840 SoC
- Bluetooth 5 2M LE, Advertising Extensions, CSA #2, Coded PHY (Long Range)
- Bluetooth Mesh
- IEEE 802.15.4 with Thread and Zigbee support
- Complete RF solution with U.FL connector for an external antenna
- Integrated DC-DC converter
- No external components required
- Arm Cortex-M4F 32-bit processor
- 1 MB embedded flash memory
- 256 kB RAM
- 48 general general-purpose I/O pins
- One full-speed USB (12 Mbps)
- NFC-A tag interface for OOB pairing
- Footprint compatible with BMD-300, BMD-301, BMD-330, BMD-340, and BMD-361
- Dimensions: 15.0 mm x 10.2 mm x 1.9 mm
Applications
- Climate control
- Lighting products
- Safety and security
- Home appliances
- Access control
- Home appliances
- Internet of Things (IoT)
- Home healthcare
- Advanced remote controls
- Smart energy management
- Low-power sensor networks
- Interactive entertainment devices
- Environmental monitoring
- Hotel automation
- Office automation
